Dilution Unit DIL-1
Part No.: 20S4900
Product features
Dilution unit for diluting sample gas
Installed on a mounting plate
With a dilution ratio of 30-40:1 as standard, optionally in the range from 10:1 to 500:1
2 internal filters for sample and dilution gas are provided to protect the dilution section
With check valve for test gas
Material of sample-contacting parts: stainless steel, quartz glass, Viton®
Optionally: bypass injector DIL-1/B to shorten the response time during vacuum operation; second sample gas outlet 2 x AUS for undiluted sample gas; add-on set DIL-1/-A with 1 precision pressure controller and 2 vacuum pressure gauges; add-on set DIL-1/-A-FM with 2 ball valves, 1 precision pressure controller, 2 vacuum pressure gauges and 1 flow meter for test gas feeding; control panel DIL-1/-S with 1 pressure controller and 2 pressure gauges, 1 flow meter and 2 shut-off valves
The non-heated M&C dilution unit DIL-1 is used in analytical technology to dilute the sample gas or components in the sample for example in the case of toxic gases, moisture measuring or emission measuring. The M&C dilution unit is based on the functional dilution technique which has proved itself in the M&C gas sample probe SP2000-H/DIL for years.
Dilution unit type DIL‑1, non‑heated, installed on a mounting plate, dilution ratio: 30‑40:1 (standard), consisting of: dilution section, 2 filters for sample gas and dilution gas, check valve for calibration gas
